Eco Friendly Heavy Steel Structure 3D Drawing Industrial Heavy Metal Workshop

Eco Friendly Heavy Steel Structure 3D Drawing Industrial Heavy Metal Workshop

Brand Name:	XGZ
Model Number:	XGZ-HSS012
MOQ:	100 square meters
Price:	USD 30-80 per square meter/Negotiable
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	30000 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

Pingdu, Qingdao, China

Certification:

CE EN1090, ISO9001,GOST,AISC

Name:

Heavy Steel Structure

Processing Service:

Bending, Welding, Decoiling, Cutting, Punching

Keyword:

Heavy Steel Structure Building

Span:

Customized

Main Frame:

Solid H-shape Steel Beam, Column

Drawing Design:

3D Drawing

Packaging Details:

Steel pallet

Highlight:

Eco Friendly Heavy Steel Structure

Heavy Steel Structure 3D Drawing

Industrial Heavy Metal Workshop

Product Description

Eco-Friendly Durable Heavy Steel Structure Building For Industrial Applications

Heavy steel structure building is composed of steel structure members including H section steel column, H section steel beam, C/Z section purlin, bracing and cladding, which form the load-bearing structure of the building. These structures are in high demand due to rapid production, easy transport and fast construction. As a cost-efficient building type, they have become the preferred choice for industrial and commercial construction.

We provide accurate budgets, construction plans and detailed drawings tailored to your specific applications and requirements. All steel structure sections and panels are factory-fabricated to precise dimensions and assembled on-site using bolts and self-tapping screws.

Product Specifications

Main Components

Primary Framing: Composed of steel beams, columns, and trusses made from section steel and steel plate, treated with rust removal and anti-rust processes including shot blasting, painting and galvanizing. Members are connected via welding, bolts or rivets.
Secondary Framing: Connects the main frame and resists longitudinal loads (wind, earthquake). Includes steel purlins (1.8-3.0mm thickness, galvanized) and column bracing for structural stability.
Cladding System: Steel sheet (galvanized or aluminium zinc with organic coating) or sandwich panels (EPS, fiberglass wool, rock wool, or PU core between steel sheets).

Component	Material Specification
Main Frame - Column	Q235, Q355 welded H section steel
Main Frame - Beam	Q235, Q355 welded H section steel
Secondary Frame - Purlin	Q235 Z/C steel purlin
Wall Panel	EPS sandwich panel/glass fiber sandwich panel/rock wool sandwich panel/PU sandwich panel/steel sheet
Roof Panel	Sandwich panel and corrugated steel sheet

Key Advantages

Clear Span: Up to 45m spans with H section columns/beams; larger spans available with truss roofs
Quality Assurance: Factory-manufactured under strict quality control
Low Maintenance: High-quality paint systems ensure durability
Design Flexibility: Compatible with canopies, curved eaves, concrete walls, curtain walls, etc.
Fast Construction: Bolt-on assembly reduces erection time

Eco Friendly Heavy Steel Structure 3D Drawing Industrial Heavy Metal Workshop 0

Eco Friendly Heavy Steel Structure 3D Drawing Industrial Heavy Metal Workshop 1

Design & Quotation Requirements

For accurate quotation, please provide:

Project location
Dimensions (length × width × eave height)
Mezzanine requirements (if any) including load capacity
Wall type preference (single-layer steel or sandwich panel)
Snow load and wind speed/load specifications
Interior column allowance
Crane requirements (capacity if needed)
Any special requirements

Eco Friendly Heavy Steel Structure 3D Drawing Industrial Heavy Metal Workshop 2

Manufacturing Process

Cutting: Precision cutting using automatic laser machines
Assembly: Components fitted per engineering drawings
Welding: Secure joining for enhanced load-bearing capacity
Surface Preparation: Rust removal via sandblasting/chemical cleaning
Finishing: Spray painting or hot-dip galvanizing

Packaging & Shipping

The packing method for main steel frame will use steel pallet, which can be better to protect steel frame and make the loading and unloading faster and more convenient since it could be taken as a whole. It could also save the quantity of shipping containers and cost of ocean freight.

Other parts packed in parcels such as steel purlin and steel sheet, all loaded into 40ft HQ. Safe and easy handle.

Eco Friendly Heavy Steel Structure 3D Drawing Industrial Heavy Metal Workshop 3

Why Choose Us

Professional engineering and construction teams with extensive experience
Comprehensive project planning to ensure timely completion
Strict adherence to safety and quality standards
ISO 9001:2015 certified manufacturing
Modern production facilities with advanced technology
Competitive pricing based on actual requirements
Global export experience to 80+ countries

Eco Friendly Heavy Steel Structure 3D Drawing Industrial Heavy Metal Workshop 4

Frequently Asked Questions

Are you a manufacturer?

Yes, we operate our own factory and offer competitive pricing.

Do you offer design services?

We provide customized designs based on your building specifications.

Can you assist with installation?

We provide detailed installation guides and can send technical teams for on-site supervision.

How to order?

Provide your drawings or requirements - we'll handle design and production.

Production timeline?

Typically 2 weeks for drawings and 30-55 days for delivery (varies by complexity).
