30x80 Heavy Structural Fabrication Prefabricated 3D Drawing

30x80 Heavy Structural Fabrication Prefabricated 3D Drawing

Brand Name:	XGZ
Model Number:	XGZ-HSS010
MOQ:	100 square meters
Price:	USD 30-100 per square meter/Negotiable
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	30000 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

Pingdu, Qingdao, China

Certification:

CE EN1090, ISO9001,GOST,AISC

Name:

Heavy Steel Structure

Processing Service:

Bending, Welding, Decoiling, Cutting, Punching

Keyword:

Heavy Steel Structure Building

Material:

Steel

Main Frame:

Solid H-shape Steel Beam, Column

Drawing Design:

3D Drawing

Packaging Details:

Steel pallet

Highlight:

30x80 Heavy Structural Fabrication

Heavy Structural Fabrication Prefabricated

Heavy Structural Steel 3D Drawing

Product Description

30x80 Heavy Structural Fabrication Prefabricated 3D Drawing

Product Description

Prefabricated heavy steel structure buildings represent innovative construction solutions offering economical pricing, convenient transportation, and quick installation. These structures are composed of H steel columns, H steel beams, purlins, roof sheets, wall sheets, rolling doors, and windows. The main structural components (H columns & beams) are secured with high-strength bolts, while purlins are fixed to columns and beams using 4.8S bolts, enabling faster erection compared to traditional concrete systems. The roof and walls utilize lightweight steel sheets or sandwich panels for efficient assembly.

Product Parameter

Components of heavy steel structure building:

Primary Framing Elements: H-section steel columns and beams (hot rolled/welded) with factory primer and protective coatings for rust prevention
Secondary Framing Elements: Purlins and tie bars fixed with common bolts
Bracing: Round steel knee bracing for enhanced structural stability
Cladding: Color-coated corrugated steel sheets or sandwich panels with zinc-aluminum coating
Windows and Doors: Plastic steel/aluminum-alloy windows; sliding/folding doors
Optional Components: Gutters, downpipes, transparent sheets, ventilators, bridge cranes

30x80 Heavy Structural Fabrication Prefabricated 3D Drawing 0

Name	Heavy Steel Structure
Main Steel Frame	Column: Q235, Q355 Welded H Section Steel Beam: Q235, Q355 Welded H Section Steel
Secondary Frame	Purlin: Q235 C and Z purlin Knee Brace: Q235 Angle Steel Tie Rod: Q235 Circular Steel Pipe Brace: Q235 Round Bar Vertical/Horizontal Support: Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance System	Roof System: Roof Panel (EPS/Fiber Glass Wool/Rock Wool/PU Sandwich Panel or Steel Sheet Cover) Wall System: Sandwich Panel or Corrugated Steel Sheet Window System: Aluminum Alloy Window/PVC Window/Skylight Door System: Sliding Sandwich Panel Door/Rolling Metal Door/PVC Door Others: PVC Rainspout, Gutter etc.

Production Features

High strength and stability: Welded pipes and H-beams made of high-tensile strength steel
Corrosion resistance: Surface-treated steel for oxidation prevention
Installation convenience: Design optimized for easy assembly
Diversified specifications: Customizable to project requirements
Quality control: Strict inspection procedures ensuring compliance with standards

Design and Quote

Our design team creates customized solutions based on your specifications. For accurate quotation and design, please provide:

Local maximum wind speed
Snow load (if applicable)
Building dimensions (length * width * eave height)
Preferred roof/wall materials
Crane requirements (including lift capacity if applicable)
Existing drawings or specifications

30x80 Heavy Structural Fabrication Prefabricated 3D Drawing 1

Product Processing

Workshop manufacturing process:

Material Preparation: Quality inspection and organization of steel components
Cutting and Shaping: Precision cutting and forming using advanced techniques
Welding and Joining: Arc/gas welding for strong structural connections
Surface Treatment: Shot blasting and painting for corrosion resistance
Packaging and Storage: Secure packaging for transportation readiness

30x80 Heavy Structural Fabrication Prefabricated 3D Drawing 2

30x80 Heavy Structural Fabrication Prefabricated 3D Drawing 3

Packaging

Main steel frames are packed on steel pallets for secure transportation and efficient container space utilization. Secondary components (purlins, steel sheets) are carefully parceled and containerized for safe shipping.

30x80 Heavy Structural Fabrication Prefabricated 3D Drawing 4

Installation Process

Prefabricated construction schedule:

Anchor bolt construction
Steel columns installation
Steel platform beams
Stud welding on decking sheet
Roof steel beams erection
Roof and wall cladding installation
Window and door installation

Our Advantages

Experienced engineering team with 10+ years in architecture
Comprehensive service including construction drawings, calculations, and foundation design
Detailed 3D drawings and numbered components for easy installation
Extra components provided to account for installation damages
Advanced manufacturing equipment including gantry planing machines and automatic welding systems
Detailed packing lists for efficient unloading
Customer-focused quality guarantee

30x80 Heavy Structural Fabrication Prefabricated 3D Drawing 5

FAQ

1. What kind of company are you?

We are a steel structure building manufacturer located in Qingdao, China, with our own factory. We welcome quality inspections and visits.

2. Do you offer designing service for us?

Yes, we provide complete design solutions using AutoCAD, PKPM, MTS, 3D3S, Tarch, and Tekla Structures (Xsteel).

3. Can you send engineers to install my structures?

We provide detailed installation drawings/videos free of charge, and can dispatch engineers as installation directors upon request.

4. What is the delivery time?

Typically 30-55 days after deposit receipt, depending on order quantity.

5. How long does it take to get my building?

Approximately 2 weeks for drawings and 30-55 days for delivery (varies by project complexity).
