Q355 Q235 Steel Frame Building Commercial Economy Metal Buildings

Q355 Q235 Steel Frame Building Commercial Economy Metal Buildings

Brand Name:	XGZ
Model Number:	XGZ-SSW057
MOQ:	500 square meters
Price:	USD30-75 Per Square Meter
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	30000 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao, China

Certification:

CE, ISO9001, AISC, GOST

Name:

Economy Metal Buildings

Standard:

GB, EN, ASTM, BS, JIS, GOST

Brand Name:

XGZ

Processing Service:

Bending, Welding, Decoiling, Cutting, Punching

Type:

Light/Heavy

Grade:

Q355,Q235/A36,A572 Gr50/S235JR,S355JR

Color:

Requirement

Keyword:

Steel Structure Workshop Building

Packaging Details:

Steel pallet, In bulk

Highlight:

Commercial Economy Metal Buildings

Q355 Steel Frame Building Commercial

Q235 Steel Frame Building Commercial

Product Description

Economic Prefabricated Shed Building Workshop Industrial Steel Structure Warehouse

Product Description

Steel structure building is a construction type where steel acts as the primary load-bearing material, composing key structural components (beams, columns, trusses, frames) to resist vertical and horizontal loads. It features high strength-to-weight ratio, prefabrication suitability, and large-span adaptability, applied in industrial, commercial, and infrastructure projects.

Product Parameter

Main frame of steel structure workshop:

Primary Framing Elements: Columns, beams members are made by H section steels (hot rolled section steel/welded section steel), which will be easily bolted together at site. A factory primer and facing paintings or galvanization surface treatment are applied to get better anti-rusting effect.
Secondary Framing Elements: Purlin, tie bar are formed as secondary framing, which will fix on columns and beams by common bolts.
Bracing: Round steel is supplied with knee bracing and other supporting parts that need portal framing, which will improve the stability and durability of the whole structural hangar.
Cladding: Roof and Wall are covered by color-coated corrugated steel sheet or steel sandwich panel, hot dipped with zinc and aluminum compound, that is fixed to the outside of structural building to protect it against bad weather.
Windows and Doors: Plastic Steel Window/Aluminum-alloy Window; Sliding Door/Folding Door.
Other Options: Gutter, Downpipe, Transparent sheet, Ventilator and Bridge Crane will be fitted according to client's requirements.

Q355 Q235 Steel Frame Building Commercial Economy Metal Buildings 0

Items	Specification
Main steel frame	Steel column: H section steel Steel beam: H section steel
Secondary frame	Purlin: Q235 C and Z purlin Knee brace: Q235 Angle Steel Tie rod: Q235 Circular Steel Pipe Brace: Q235 Round Bar Vertical and horizontal support: Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance system	Roof panel: EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel / Steel Sheet Wall panel: Sandwich Panel / Corrugated Steel Sheet
Accessories	Windows: Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window Doors: Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door Rainspout: PVC
Paint options	Alkyd paiting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized.

Product Features

Compared with traditional concrete buildings, steel structure buildings have many advantages:

Wide span: single span or multiple spans, the max span is 36m without middle column
Low cost and maintenance: unit price range from USD35/m² to USD70/m² according to customers request
Fast construction and easy installation: time saving and labor saving
Long using life span: up to 50 years
Nice appearance
Environmental protection, stable structure, High quake-proof, water proof and fire proof, and energy conserving

Customization

Our products are fully customizable to meet the specific needs of clients. We have a team of professional technicians who specialize in designing. Please provide the following information:

Project site location
Overall dimension (length*width*eave height)
Mezzanine requirements and load capacity
Wall material preference (single-layer steel sheet or sandwich panel)
Snow load if applicable
Wind speed/load
Interior column requirements
Overhead crane needs and capacity

Q355 Q235 Steel Frame Building Commercial Economy Metal Buildings 1

Q355 Q235 Steel Frame Building Commercial Economy Metal Buildings 2

Why Choose Us?

Professional Teams: Skilled engineers and construction teams with years of experience
Quality Assurance: Projects meet building codes and designed to last for years
Safety First: All technical standards supervised at the highest level
International Standards: ISO 9001:2015 certified production
Factory Capacity: 9 professional production lines with advanced equipment
Competitive Pricing: Comprehensive solutions with best value
Global Experience: Successfully exported to 130 countries worldwide

Q355 Q235 Steel Frame Building Commercial Economy Metal Buildings 3

Q355 Q235 Steel Frame Building Commercial Economy Metal Buildings 4

FAQ

Q: Are you a manufacturer or trading company?
A: We are a manufacturer with our own factory. Customers are welcome to visit for inspection.

Q: Do you offer custom designs?
A: Yes, our engineering team can create designs based on your requirements.

Q: What payment methods do you accept?
A: We accept T/T and irrevocable L/C at sight.

Q: How is installation handled?
A: We provide detailed installation instructions and videos. On-site technician assistance is available (additional costs apply).

Q: What is the delivery time?
A: Typically 40 days after receiving deposit, depending on order quantity.
