Customized Steel Structure Warehouse Hot Galvanized Steel Frame Buildings

Customized Steel Structure Warehouse Hot Galvanized Steel Frame Buildings

Brand Name:	XGZ
Model Number:	XGZ-SSW012
MOQ:	100 square meters
Price:	USD 30-80 per square meter
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	30000 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao, China

Certification:

ISO9001,CE,GOST,AISC

Name:

Steel Structure Warehouse

Application:

Steel Workshop, Warehouse

Processing Service:

Bending, Welding, Decoiling, Cutting, Punching

Material:

Q355, Q235 Steel

Wall & Roof Panel:

Steel Sheet Or Sandwich Panel

Drawing Design:

AutoCAD, 3D3S, Etc..

Technology:

Welded Steel, Hot Rolled Steel

Color:

Customized Color

Packaging Details:

Steel Pallet

Highlight:

Customized Painted Steel Structure Warehouse

Steel Structure Warehouse Hot Galvanized

Hot Galvanized Steel Frame Buildings

Product Description

Customized Painted Steel Structure Warehouse Hot Galvanized

Product Description

Prefabricated steel structure warehouses offer a cost-effective alternative to traditional brick or concrete structures. These warehouses provide excellent protection against weather elements while featuring factory-made components that are pre-cut, pre-welded, pre-drilled, and pre-painted for easy on-site assembly with bolts.

Steel structures have largely replaced reinforced concrete in many countries due to their advantages including light weight, large spans, material efficiency, cost savings, foundation economy, quick construction cycles, and attractive appearance.

Product Specification

Components of our steel structure buildings include:

Primary Framing Elements: H-section steel columns and beams (hot rolled or welded) with factory primer and painted/galvanized surfaces for rust prevention
Secondary Framing Elements: Purlins and tie bars fixed to columns and beams with common bolts
Bracing: Round steel knee bracing and supporting parts to enhance structural stability
Cladding: Color-coated corrugated steel sheets or sandwich panels for weather protection and aesthetics
Windows and Doors: Plastic steel or aluminum-alloy windows; sliding or folding doors
Optional Features: Gutters, downpipes, transparent sheets, ventilators, and bridge cranes available upon request

Items	Specification
Main Steel Frame - Column	Q235, Q355 Welded H Section Steel
Main Steel Frame - Beam	Q235, Q355 Welded H Section Steel
Secondary Frame - Purlin	Q235 C and Z purlin
Knee Brace	Q235 Angle Steel
Tie Rod	Q235 Circular Steel Pipe
Brace	Q235 Round Bar
Vertical and Horizontal Support	Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance system - Roof Panel	EPS Sandwich Panel, Glass Fiber Sandwich Panel, Rock Wool Sandwich Panel, Pu Sandwich Panel, Steel Sheet
Maintenance system - Wall Panel	Sandwich Panel, Corrugated Steel Sheet
Accessories - Window	Aluminiumn Alloy Window, PVC Window, Sandwich Panel Window
Accessories - Door	Sliding Sandwich Panel Door, Rolling Metal Door, Personal Door
Accessories - Rainspout	PVC

Our raw materials are sourced from one of China's largest steel mills, ensuring consistent quality and reliable delivery. This strategic partnership enables streamlined production processes and guaranteed project timelines.

Customized Steel Structure Warehouse Hot Galvanized Steel Frame Buildings 0

Product Advantages

Free design and architectural drawings provided
50-year designed lifespan with easy maintenance
Quick assembly with online installation guidance
Engineered for high wind resistance
Thermal and noise insulation with waterproof and fire prevention properties

Customized Steel Structure Warehouse Hot Galvanized Steel Frame Buildings 1

Product Design

We can provide immediate quotations for existing drawings or offer free design services for conceptual projects. To assist with design, please provide:

Location: Country and city
Size: Length × Width × Eave height
Maximum wind speed
Maximum snow height
Earthquake resistance level
Brick wall requirements (if applicable)
Insulation preferences (sandwich panel or corrugated steel sheet)
Door and window specifications
Crane requirements (if needed)

Customized Steel Structure Warehouse Hot Galvanized Steel Frame Buildings 3

Production Process

Cutting: Precision cutting using laser machines according to design specifications
Assembly: Component assembly using hydraulic positioning systems
Welding: Automated submerged arc welding following strict sequence and parameters
Rust Removal: Shot blasting to Sa2.5 standard
Surface Treatment: Custom painting or hot-dip galvanizing

Customized Steel Structure Warehouse Hot Galvanized Steel Frame Buildings 4

Product Packaging

Main steel frames are secured on steel pallets for efficient handling and container space optimization. Secondary components are carefully packed in parcels for safe container shipping.

Customized Steel Structure Warehouse Hot Galvanized Steel Frame Buildings 5

Why Choose Us?

Xinguangzheng Group provides comprehensive steel structure solutions:

Custom design using Tekla, PKPM, and 3D3S software
Professional consultation and budget planning
Flexible transportation and delivery options
Custom fabrication with various surface treatments
On-site erection support with technical guidance

Customized Steel Structure Warehouse Hot Galvanized Steel Frame Buildings 6

Customized Steel Structure Warehouse Hot Galvanized Steel Frame Buildings 7

Customized Steel Structure Warehouse Hot Galvanized Steel Frame Buildings 8

Customized Steel Structure Warehouse Hot Galvanized Steel Frame Buildings 9

FAQ

Is your company a factory or trade company?

We are a factory, ensuring you receive the best competitive pricing.

Can you offer design service?

Yes, our engineering team provides complete design services including architectural drawings, structure diagrams, and installation plans at each project phase.

Do you offer service for installation?

We provide detailed construction manuals and can dispatch engineers for on-site installation support when needed.

What's the payment term?

30% deposit with 70% balance due before shipment.

Do you accept container loading inspection?

We welcome inspectors at any production stage, including container loading.
