Fast Assembly PEB Structure Warehouse Q235 Q355 Steel Construction Factory Building

Fast Assembly PEB Structure Warehouse Q235 Q355 Steel Construction Factory Building

Brand Name:	XGZ
Model Number:	XGZ-SSW013
MOQ:	100 square meters
Price:	USD 30-80 Square Meter/Negotiable
Payment Terms:	L/C,T/T,Western Union,MoneyGram
Supply Ability:	30000 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao

Certification:

CE,ISO9001,GOST,AISC

Name:

Steel Construction Factory Building

Design Style:

Modern

Surface Treatment:

Hot Dip Galvanised Or Painted

Material:

Q235, Q355

Standard:

AiSi, ASTM, DIN, GB, JIS

Application Fields:

Steel Structural Fabrication Construction

Packaging Details:

Steel pallet

Highlight:

Fast Assembly PEB Structure Warehouse

PEB Structure Warehouse Q235

Q355 Steel Construction Factory Building

Product Description

Environmentally Friendly PEB Structure Warehouse With Fast Assembly

Factory-Made Steel Structure Warehouse With Fast Assembly And Low Cost

Steel structure PEB warehouse is composed of a series of steel structure members, including H section steel column, H section steel beam, C/Z section purlin, bracing and cladding, which form the load-bearing structure of the building. These warehouses are in high demand due to their lightweight steel structure, easy transport and fast construction. As a cost-efficient building type, PEB warehouses have become the preferred choice for industrial and commercial construction.

We provide accurate budgets, construction plans and detailed drawings tailored to your specific requirements. All steel structure sections and panels are factory-fabricated to precise dimensions and assembled on-site using bolts and self-tapping screws.

Product Features

Large span design: Creates open internal space ideal for storage and operation of large equipment
Fast construction speed: Prefabricated components enable quick on-site assembly
Lightweight: Reduces foundation loads and construction costs compared to concrete
Excellent seismic performance: Steel's toughness ensures safety during earthquakes
Durability: Corrosion protection extends service life in harsh environments
High flexibility: Customizable designs adapt to various production needs
Environmental friendliness: Recyclable materials support sustainability
Low maintenance costs: Simple upkeep requirements reduce long-term expenses

Product Parameters

Main Frame Components

H steel column and beam
C section or Z section roof and wall purlin
Round tube steel tie bar
Round steel bracing
Color steel sheet/sandwich panel roof and wall
Sandwich panel sliding door/Rolling door
PVC window/Aluminium window

Items	Specification
Main Steel Frame	Column: Q235, Q355 Welded H Section Steel Beam: Q235, Q355 Welded H Section Steel
Secondary Frame	Purlin: Q235 C and Z purlin Knee brace: Q235 Angle Steel Tie rod: Q235 Circular Steel Pipe Brace: Q235 Round Bar Vertical & Horizontal support: Q235 Angle Steel, Round Bar or Steel Pipe
Cladding System	Roof panel: EPS Sandwich Panel / Glass Fiber Sandwich Panel Rock Wool Sandwich Panel / Pu Sandwich Panel / Steel Sheet Wall panel: EPS Sandwich Panel / Glass Fiber Sandwich Panel Rock Wool Sandwich Panel / Pu Sandwich Panel / Steel Sheet
Accessories	Window: Aluminium Alloy Window / PVC Window Door: Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door Rainspout: PVC
Other Options	Crane 5T, 6T, 10T, 16T, 30T etc.

Fast Assembly PEB Structure Warehouse Q235 Q355 Steel Construction Factory Building 0

Design and Quote

We provide customized solutions based on your drawings, plans or ideas. For accurate quotes, please provide:

Project location (country and city)
Maximum wind speed at site
Maximum snow load at site
Preferred roof and wall material (color steel sheet or sandwich panel)
Quantity and size of windows and doors
Crane specifications if required

Fast Assembly PEB Structure Warehouse Q235 Q355 Steel Construction Factory Building 1

Product Processing

Cutting: Precision cutting of steel components using automatic laser cutting machines
Assemble: Fitting steel pieces according to engineering drawings
Welding: Creating strong, resilient connections for enhanced load-bearing capacity
Rust removal: Surface preparation using sandblasting or chemical cleaning
Surface treatment: Spray painting or hot-dip galvanizing for corrosion protection

Clients are welcome to visit our factory to inspect production processes and quality before ordering, as well as during production and at delivery.

Fast Assembly PEB Structure Warehouse Q235 Q355 Steel Construction Factory Building 2

Fast Assembly PEB Structure Warehouse Q235 Q355 Steel Construction Factory Building 3

Company Profile

Qingdao Xinguangzheng Steel Structure Co., Ltd. is a specialized enterprise integrating steel structure material design, R&D, production and sales. Located in Qingdao Overseas Chinese Science and Technology Park, we operate advanced production equipment including Longmen planning machines, automatic submerged arc welding machines, and shot blasting rust removal machines.

Our products are sold nationwide and exported to over 100 countries including Thailand, Indonesia, Arabia, Australia, Algeria, South Africa, and Brazil. We maintain a commitment to quality, customer focus, and talent development to deliver outstanding steel structure solutions.

Fast Assembly PEB Structure Warehouse Q235 Q355 Steel Construction Factory Building 4

Fast Assembly PEB Structure Warehouse Q235 Q355 Steel Construction Factory Building 5

Frequently Asked Questions

What kind of company are you?

We are a steel structure building manufacturer located in Qingdao, China.

What information is needed for a complete quotation?

Please provide warehouse dimensions, draft drawings, layout plans and material preferences. We will then design the drawings and offer a competitive quotation.

What drawings will you provide?

Plan drawings, elevation drawings, sectional drawings, foundation drawings and installation drawings.

How long does production take?

Typically 2 weeks for drawings and 30-55 days for delivery, depending on project complexity.

Do you provide installation support?

We provide detailed installation drawings and videos. Engineers or installation teams can be provided upon request.
