Fully Personalized Prefabricated Steel Building for Maximum Use Space and Energy Efficiency

Fully Personalized Prefabricated Steel Building for Maximum Use Space and Energy Efficiency

Brand Name:	XGZ
Model Number:	XGZ-SSB031
MOQ:	100 square meters
Price:	USD 30-80 per square meter/Negotiable
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	30000 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao,China

Certification:

CE,ISO9001,GOST,AISC

Name:

Steel Structure Building

Purlin:

C, Z Galvanized Steel

Keyword:

Steel Structural Steel Frame Building

Material:

Q355 Q235

Use:

Warehouse, Workshop, Office Building, Hangar, Garage

Wall&Roof Panel:

Steel Sheet, Sandwich Panel

Packaging Details:

Steel pallet

Highlight:

Personalized Prefabricated Steel Buildings

Prefabricated Steel Buildings Maximum Space

Personalized metal frame buildings

Product Description

Fully Personalized Steel Structure Building For Maximum Use Space

Steel structure buildings utilize construction steel as their load-bearing structure, typically composed of beams, columns, trusses, and other components made from section steel and steel plates. These structures combine roof, floor, and wall enclosure systems to create durable buildings. The steel components are usually hot-rolled angle steel, channel steel, I-beam, H-section steel, and steel pipe.

Product Specification

Qingdao Xinguangzheng sources materials from China's largest steel structure manufacturers with strict quality control. Steel structures require:

Higher strength for greater load capacity with smaller sections
Better plasticity and toughness to prevent brittle failure
Excellent machining performance and durability including welding ability and corrosion resistance

Component	Specification
Main Steel Frame	Column: Q235, Q355 Welded H Section Steel Beam: Q235, Q355 Welded H Section Steel
Secondary Frame	Purlin: Q235 C and Z purlin Knee Brace: Q235 Angle Steel Tie Rod: Q235 Circular Steel Pipe Brace: Q235 Round Bar Vertical and Horizontal Support: Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance System	Roof Panel (EPS/Fiber Glass Wool/Rock Wool/PU Sandwich Panel or Steel Sheet Cover) Wall Panel (Sandwich Panel or Corrugated Steel Sheet) Window System: Aluminum Alloy Window/PVC Window/Skylight Door System: Sliding Sandwich Panel Door/Rolling Metal Door/PVC Door Others: PVC Rainspout, Gutter etc

Fully Personalized Prefabricated Steel Building for Maximum Use Space and Energy Efficiency 0

Customization

We offer complete customization services. Please provide either architectural drawings or the following information for a customized solution:

Location and dimensions (Length × Width × Eave height)
Environmental loads (wind speed, snow height, earthquake requirements)
Brickwall requirements (if any)
Thermal insulation preferences (EPS, fiberglass wool, rockwool, PU sandwich panels or metal sheets)
Door and window specifications (quantity & size)
Crane requirements

Fully Personalized Prefabricated Steel Building for Maximum Use Space and Energy Efficiency 1

Product Features

Cost Savings: 25% lower cost per square meter than conventional buildings with reduced site erection costs
Quality Control: Factory-designed and fabricated with strict quality processes
Quick Erection: Pre-fabricated components enable fast bolt-together assembly
Flexibility: Adaptable designs with easy future expansion capabilities
Energy Efficiency: Environmentally friendly solution with CO2 reduction and recyclability

Product Processing

Our manufacturing process includes:

Precision cutting using automatic laser cutting machines
Accurate assembly per engineering specifications
Secure welding for strong load-bearing connections
Thorough rust removal via sandblasting or chemical cleaning
Surface treatment with spray painting or hot-dip galvanizing

Fully Personalized Prefabricated Steel Building for Maximum Use Space and Energy Efficiency 2

Packaging and Shipping

Products are securely packaged either on pallets or in bulk containers for safe transportation. Our packaging methods ensure stability during transit and efficient handling at destination ports.

Fully Personalized Prefabricated Steel Building for Maximum Use Space and Energy Efficiency 3

Installation

We provide comprehensive installation support including:

Detailed construction drawings and instructional videos
Online installation guidance
Optional on-site technical support (additional cost)

Standard installation sequence includes anchor bolt placement, column installation, floor platform assembly, roof beam placement, and finishing components.

FAQ

What kind of company are you?

We are a steel structure building manufacturer located in Qingdao, China with full manufacturing capabilities and quality certifications.

Do you offer designing service?

Yes, we provide complete design solutions using AutoCAD, PKPM, MTS, 3D3S, Tarch, and Tekla Structures.

How about your quality control?

Our products meet CE EN1090 and ISO 9001 standards.

What's the payment term?

40% deposit with 60% balance due before shipment.

Can you provide installation help?

We provide detailed instructions and videos. On-site technical support is available at additional cost.
