Light Weight Portal Frame Steel Structure Workshop With Various Span

Light Weight Portal Frame Steel Structure Workshop With Various Span

Brand Name:	XGZ
Model Number:	XGZ-SSW021
MOQ:	100 square meters
Price:	USD30-100 Per Square Meter
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	30000 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao

Certification:

CE,ISO9001,GOST,AISC

Name:

Steel Structure Workshop

Wall Panel:

Steel Laminboard ,EPS ,RW ,PU Etc

Layout Design:

Technical Support

Standard:

Usage:

Steel Structure Workshop, Warehouse

Framework:

Light Steel Structure

Packaging Details:

Steel pallet, In bulk

Highlight:

Portal Frame Steel Structure Workshop

Light Weight Steel Structure Workshop

Various Span Steel Structure Workshop

Product Description

Light Weight Portal Frame Steel Structure Workshop With Various Span

Product Description

The structural steel workshop is designed for industrial production applications, including production workshops, auxiliary facilities, warehouses, power stations, and other purpose-built buildings. Compared to traditional concrete structures, our metal workshop buildings utilize steel plates or section steel instead of reinforced concrete, offering superior strength and impact resistance.

Our steel frame workshops are factory-painted or hot-galvanized before delivery to installation sites. The prefabricated steel components enable rapid on-site assembly, significantly reducing construction time. The recyclable nature of steel minimizes construction waste, making these structures an environmentally friendly choice for industrial and commercial applications.

Product Parameters

The steel structure workshop consists of three main systems:

Main Frame: Comprising steel beams, columns, and trusses
Secondary Supporting Frame: Including purlins, tie bars, and bracing to support wall and roof cladding
Cladding System: Featuring steel sheets (0.3mm-0.7mm thickness) or insulated sandwich panels with various core materials (EPS, fiberglass wool, rock wool, or polyurethane)

Component	Specification
Main steel frame	H section steel beam and columns, painted or galvanized
Secondary frame	Hot dip galvanized C purlin, steel bracing, tie bar, knee brace, edge cover etc.
Roof panel	EPS sandwich panel, glass fiber sandwich panel, rock wool sandwich panel, and PU sandwich panel or steel sheet
Wall panel	Sandwich Panel or Corrugated Steel Sheet
Tie Rod	Circular Steel Tube
Brace	Round Bar
Knee Brace	Angle Steel
Roof Gutter	Color Steel Sheet
Rainspout	PVC Pipe
Door	Sliding Sandwich Panel Door or rolling Metal Door
Windows	PVC/Aluminum Alloy Window

Product Features

Versatile Applications: Suitable for factories, warehouses, offices, gymnasiums, aircraft hangars, and both single-storey long-span or multi-storey buildings
Rapid Construction: Factory-prefabricated components enable fast on-site assembly
Durable & Low Maintenance: Withstands harsh weather conditions with minimal upkeep
Aesthetic Flexibility: Modern design with multiple color options for wall panels and material choices
Cost-Effective: Lightweight structure reduces foundation costs
Quick ROI: Faster construction enables earlier operational use compared to concrete structures

Light Weight Portal Frame Steel Structure Workshop With Various Span 0

Customization Requirements

To receive a customized quote for your prefabricated steel structure workshop, please provide:

Local maximum wind speed
Snow load (if applicable)
Workshop dimensions (length × width × eave height)
Preferred roof and wall materials
Crane requirements (including lifting capacity if applicable)
Any available drawings or additional specifications

Light Weight Portal Frame Steel Structure Workshop With Various Span 2

Project Process

1. Contact Us: Reach out via phone, email, or WeChat

2. Drawing & Quotation: Our team will provide optimal solutions based on your requirements

3. Contract Finalization: Confirm pricing, payment terms, and shipment schedule

4. Production: Manufacturing begins upon receipt of deposit

5. Quality Inspection: Routine checks throughout production with detailed reports

6. Packing & Shipment: Components packed on steel racks and shipped as directed

7. Installation: Complete installation drawings provided, with optional on-site guidance

8. After-Sales Support: Ongoing technical assistance for any issues

Light Weight Portal Frame Steel Structure Workshop With Various Span 3

Frequently Asked Questions

Q: Are you a manufacturer?
A: Yes, we have extensive experience in steel structure manufacturing and have served thousands of projects worldwide.

Q: How can I purchase customized products?
A: You may provide your own drawings or we can design based on your requirements and local climatic conditions.

Q: Do you provide overseas installation support?
A: Yes, we can send professional engineers for on-site supervision and training (additional service).

Q: Can we inspect before shipment?
A: Absolutely, we welcome inspections at any stage of production.

Q: Can we visit your factory?
A: We warmly welcome factory visits and will arrange professional staff to assist you.
