| Brand Name: | XGZ |
| Model Number: | XGZ-SS001 |
| MOQ: | 100 square meters |
| Price: | USD 30-80 per square meter |
| Payment Terms: | T/T,L/C,Western Union,MoneyGram |
| Supply Ability: | 30000 tons per month |
| Component | Specifications |
|---|---|
| Main Structure | Column: Q355, Q235B Welded or Hot Rolled H-steel (Box column available) Beam: Q355, Q235B Welded or Hot Rolled H-steel |
| Surface Processing | 1. Epoxy Zinc-Rich Primer + Epoxy Mica Intermediate Paint (120μm thickness) 2. Hot Dip Galvanization |
| Sub Structure | Purlin: Q355B C/Z Section Steel Angle Brace: Q235B L-Steel Cross Bracing: Q235B Round Bar, L-Steel Tie Bar: Q235B Round Pipe Batter Brace: Q235B Round Bar |
| Roof System | Roof Panel Options: 1. Insulated Sandwich Panel (PU, Rock Wool, Glass Fiber, EPS) - 50mm/75mm/100mm thickness 2. Steel Plate - 0.4mm/0.5mm thickness Gutter Options: 1. Galvanized Steel Gutter - 2.0mm/2.5mm/3.0mm thickness 2. Painted, Pre-finished Steel Gutter - 0.4mm/0.5mm/0.6mm thickness Downspout: PVC Pipe |
| Wall System | Wall Panel Options: 1. Insulated Sandwich Panel (PU, Rock Wool, Glass Fiber, EPS) - 50mm/75mm/100mm thickness 2. Steel Plate - 0.4mm/0.5mm thickness 3. Brick Wall (provided by client) Door Options: Roller Door, Sliding Door, Access Door (Steel/Glass) Window Options: PVC or Aluminum Frame (Fixed, Swing, Sliding) |
| Accessories | Anchor Bolts, Chemical Bolts, High Strength Bolts, Ordinary Bolts, Self-Drilling Screws, Rivets |
