Modern Sustainable Steel Aircraft Hangar Eco Friendly Prefabricated Aircraft Hangars

Modern Sustainable Steel Aircraft Hangar Eco Friendly Prefabricated Aircraft Hangars

Brand Name:	XGZ
Model Number:	XGZ-SSH004
MOQ:	100 square meters
Price:	USD 30-80 per square meter/Negotiable
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	30000 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao,China

Certification:

CE EN1090,ISO9001,GOST,AISC

Name:

Steel Aircraft Hangar

Standard:

Internatinal Standard

Type:

Light

Application:

Airplane Hangars

Surface Treatment:

Hot Dip Galvanized, Painted

Drawing Design:

SAP2000, AutoCAD, PKPM, 3D3S, TEKLA

Packaging Details:

Steel pallet

Highlight:

Modern Steel Aircraft Hangar

Sustainable Steel Aircraft Hangar

Eco Friendly Prefabricated Aircraft Hangars

Product Description

Modern Prefabricated Aircraft Hangars Sustainable Eco-Friendly

Modern Steel Structure Hangar For Sustainable And Eco-Friendly Construction

Prefabricated steel structure hangar represents innovative building construction technology. Its economical pricing, convenient transportation, and quick installation make it increasingly popular in construction projects.

The hangar consists of H steel columns, H steel beams, purlins, roof sheets, wall sheets, rolling doors, and windows. The main structure (H columns & beams) is secured with high-strength bolts, while purlins are fixed with 4.8S bolts, enabling faster assembly than traditional concrete systems. The roof and walls use lightweight steel sheets or sandwich panels for efficient installation.

Product Specification

Main frame: Steel beams, steel columns, steel trusses
Secondary supporting framing: Purlin, tie bar and bracing to support wall and roof cladding
Roof and wall cladding system: Steel sheet thickness 0.3mm-0.7mm or sandwich panel with insulation core (EPS, fiberglass wool, rock glass wool, or PU)

Steel Structure Hangar Specifications
Main steel frame	Column: H section steel Q355B, alkyd painting Beam: H section steel Q355B, alkyd painting
Steel purlin	Roof purlin: C or Z shape, galvanized steel Q235B Wall purlin: C or Z shape, galvanized steel Q235B
Cladding material	Roof: PPGI steel sheet or sandwich panel (EPS, Fiberglass, Rockwool, PU) Wall: PPGI steel sheet or sandwich panel (EPS, Fiberglass, Rockwool, PU)
Accessories	Bolts: Ordinary, high strength Gutter: Galvanized steel plate or stainless steel Windows: Aluminum alloy or PVC material Doors: Sliding or rolling door Downpipes: PVC pipe or metal pipe Edge cover: PPGI steel sheet 0.5mm thickness Ventilation: Stainless steel ventilation

Modern Sustainable Steel Aircraft Hangar Eco Friendly Prefabricated Aircraft Hangars 0

Features Of Steel Structure Hangar

Large Clear Span: Up to 45m with H section steel; larger spans available with truss roofs
Quality Control: Factory-manufactured components under strict quality standards
Low Maintenance Cost: High-quality paint systems ensure durability and minimal upkeep
Architectural Versatility: Customizable with canopies, curved eaves, various wall/roof options
Fast Construction: Prefabricated components enable quick bolt-together assembly

Design and Quotation

Share your drawings for accurate quotation. Our design team can create customized solutions based on:

Project location
Dimensions (Length × Width × Eave Height)
Wind load (maximum wind speed)
Snow load (maximum snow height)
Earthquake resistance level
Brick wall requirements (if needed)
Insulation preferences (EPS, fiberglass, rockwool, PU panels or metal sheets)
Door and window specifications (quantity and sizes)

Modern Sustainable Steel Aircraft Hangar Eco Friendly Prefabricated Aircraft Hangars 1

Our Company

Qingdao Xinguangzheng Steel Structure Co., Ltd., located in Qingdao Overseas Chinese Science and Technology Park, specializes in steel structure design, R&D, production, and sales. Our facility features advanced equipment including Longmen planing machines, automatic submerged arc welders, assembly machines, slitters, and shot blasting machines.

Our products, including color steel tiles and composite panels, are used domestically and exported to South Korea, Arabia, Australia, Algeria, South Africa, Brazil, and other regions.

Modern Sustainable Steel Aircraft Hangar Eco Friendly Prefabricated Aircraft Hangars 2

Our Service

Experienced engineering team with 10+ years in architecture
Comprehensive service including construction drawings, calculations, and foundation design
3D visualization and numbered components for easy installation
Extra materials provided to account for potential installation damage
Prompt response to all inquiries and questions
Advanced processing equipment for precision manufacturing
Detailed packing lists for efficient unloading

Customers Visit

With 10,000+ successful overseas projects, we offer complete capabilities in steel structure design, manufacturing, and construction. We welcome factory visits to showcase our advanced facilities and quality processes.

Modern Sustainable Steel Aircraft Hangar Eco Friendly Prefabricated Aircraft Hangars 3

FAQ

1. What kind of company you are?

We are a steel structure building manufacturer based in Qingdao, China.

2. How to get a quote from you?

3. Do you offer service for installation?

We provide detailed construction drawings and manuals. Engineers can be dispatched for on-site assistance if required.

4. What's the payment term?

30% deposit, 70% balance before shipment.

5. Do you accept container loading inspection?

Inspections are welcome during production or at loading.
