Q235B Q355B Industrial Steel Structure Workshop Building Customized

Q235B Q355B Industrial Steel Structure Workshop Building Customized

Brand Name:	XGZ
Model Number:	XGZ-SSW008
MOQ:	100 square meters
Price:	USD30-80 Per Square Meter
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	30000 tons per month

Detail Information

Product Description

Detail Information

Place of Origin:

Qingdao

Certification:

CE,ISO9001,GOST,AISC

Name:

Industrial Steel Structure Workshop Building

Type:

Lightweight

Material:

Q235B, Q355B

Color:

Customized

Standard:

Usage:

Steel Structure Workshop, Warehouse

Packaging Details:

Steel pallet, In bulk

Highlight:

Q235B Industrial Steel Structure Workshop

Q355B Industrial Steel Structure Workshop

Industrial Steel Structure Workshop Building

Product Description

Light Weight Steel Structure Workshop For Industrial Production

Versatile And Practical Steel Structure Workshop For Various Loads And Spans

The structural steel workshop is a building solution designed for industrial production. This industrial steel structure includes production workshops, auxiliary production areas, warehouses, and other purpose-built facilities.

Compared with traditional concrete buildings, our metal steel structure workshops use steel plates or section steel instead of reinforced concrete, offering superior strength and impact resistance. The steel frames are factory-painted or hot-galvanized before delivery to the installation site. The prefabrication process significantly reduces construction time while the recyclability of steel minimizes construction waste, making it an environmentally friendly choice for both industrial and civil buildings.

Product Parameters

Main Components

Main frame: Steel beams, steel columns, steel trusses
Secondary supporting frame: Purlin, tie bar and bracing for wall and roof support
Roof and wall cladding system: Steel sheet (0.3mm-0.7mm) or sandwich panels with various insulation cores (EPS, fiberglass wool, rock wool, PU)

Items	Specification
Material	Q235B, Q355B
Main frame	H-shape Steel Beam, Column
Purlin	C, Z-Shape Steel Purlin
Roof and wall	1. Color-Coated Corrugated Steel Sheet; 2. Rock Wool Sandwich Panels; 3. EPS Sandwich Panels; 4. Glass Wool Sandwich Panels
Door	1. Rolling Gate; 2. Sliding Door
Window	1. PVC Steel 2. Aluminum Alloy
Down spout	Round Pvc Pipe
Ventilation	1. Turbine vent 2. Ridge vent 3. Custom solutions
Other materials	Self-Screwing Tapping, Bolt, Nut, etc.

Product Features

Large span design: Open internal space for storage and operation of large equipment
Fast construction: Prefabricated components reduce installation time significantly
Lightweight: Lower foundation loads compared to concrete structures
Seismic performance: Superior toughness and ductility for safety in extreme conditions
Durability: Corrosion protection ensures long service life
Flexibility: Customizable designs to meet various production needs
Eco-friendly: Recyclable materials support sustainable development
Low maintenance: Simple upkeep requirements reduce long-term costs

Q235B Q355B Industrial Steel Structure Workshop Building Customized 0

Customization Requirements

To receive a customized quote for your prefabricated steel structure workshop, please provide:

Local maximum wind speed
Snow load data (if applicable)
Workshop dimensions
Technical drawings or specifications (if available)

Q235B Q355B Industrial Steel Structure Workshop Building Customized 2

About Our Company

Qingdao Xinguangzheng Steel Structure Co., Ltd., located in Qingdao Overseas Chinese Science and Technology Park, specializes in steel structure material design, R&D, production, and sales. Our facility features advanced production equipment including Longmen planing machines, automatic submerged arc welders, and shot blasting rust removal systems.

Our innovative steel structure building materials are used worldwide, with exports to over 100 countries including South Korea, Australia, Algeria, South Africa, and Brazil.

Q235B Q355B Industrial Steel Structure Workshop Building Customized 3

Q235B Q355B Industrial Steel Structure Workshop Building Customized 4

Production Process

Lofting: Verification of installation dimensions and production samples
Material marking: Precision cutting and marking for optimal material usage
Cutting: Utilizing oxygen cutting, plasma cutting, and mechanical methods
Correction: Mechanical and flame straightening processes
Edge processing: Including planing, milling, and groove machining
Hole making: Precision drilling for various bolt and anchor requirements

Frequently Asked Questions

What kind of company are you?

We are a steel structure building manufacturer located in Qingdao, China.

What are your main products?

Our products include steel structures, warehouses, workshops, factories, office buildings, hangars, garages, and poultry houses.

Do you offer on-site installation guidance overseas?

Yes, we can provide installation supervision and training services by sending our professional technical engineers.

What information is needed for a complete quotation?

Please provide workshop dimensions, draft drawings, layout plans, and material preferences for us to prepare a competitive quote.

Can we visit your factory?

We welcome factory visits. Please share your schedule so we can arrange for our sales team to assist you.
